"The Displayed machines are specifically for the manufacturer of Tubular Heating Elements"

Soldering Machine TL - 349


Soldering Machine TL - 349
Mainly used to test pressure and resistance of the shrinked linear tube.

Functions :

1. Application range: water boiler, coffee boiler and other products.

2. PLC control: control accuracy, smooth ruuning.

3. 0peration mode: Automatic program control/manual control.

4. Small size, compact in structure, easy operation and good design.

5. The machine has the function of loading and unloading, preheat, heating, holding pressure and cooling. It can save time and improve      productivity.

6. It can also equip with whole set cooling system (including water tank, pump and corresponding spare part)


Main Technical Parameters

1. Power supply: tri-phase 380V 50Hz

2. Power: GBT transistor high frequency power 2x25KW and 2x40KW

3. Water supply: water pressure 2-3kgf/cm3, input water temperature <30oC,water flow: 2x40L/MIN

4. Air suppiy: 4-6kgf/cm2

5. Heating elements specification: Φ90 - Φ180 ( it can be custom-made)

6. Aluminum panel thickness: 1.5-2mm
